HURCO VM10UHS CNC Machine Specifications
Origin: Germany
Category: Milling CNC Vertical Machining Center 5 Axes
| Model | VM10UHS |
|---|---|
| Table size | 7.8 in / 198 mm |
| Maximum weight on rotary / trunnion table | 330 lb / 150 kg |
| Spindle nose to table (min / max) | 1.4 in (36 mm) / 20.4 in (519 mm) |
| Table T-slots | 6 x .39 in / 6 x 10 mm |
| X-axis | 21.0 in / 533 mm |
| Y-axis | 16.0 in / 406 mm |
| Z-axis | 19.0 in / 483 mm |
| A-axis | -30° / +110° |
| C-axis | 360° |
| Maximum spindle speed / tool type | 20,000 rpm / BT30 |
| Spindle power (30 min / continuous) | 11.4 hp (8.5 kW) / 10 hp (7.5 kW) @ 600 rpm |
| Spindle torque (30 min / continuous) | 4.0 ft. lbs (5.4 Nm) / 3.5 ft. lbs (4.8 Nm) @ 600 rpm |
| Tool capacity | 20 |
| Maximum tool diameter | 3.15 in / 80 mm |
| Maximum tool length | 9.8 in / 250 mm |
| Tool-to-tool ATC time | 2 sec |
| Maximum tool weight | 6.6 lb / 3 kg |
| Rapid traverse XYZ | XYZ = 1,102 in / 28 m |
| Programmable feedrate | 1,102 in / 28 m |
| C-axis maximum rpm | 25 rpm |
| Maximum operating floor space (W x D x H) | 126.1 x 133.2 x 106.9 in / 3,202 x 3,383 x 2,715 mm |
| Machine weight | 6,825 lb / 3,102 kg |
