HURCO DCX3226i CNC Machine Specifications
Origin: Germany
| Model | DCX3226i |
|---|---|
| Table size | 118.1 x 82.7 in / 3,000 x 2,100 mm |
| Maximum weight on table | 30,864 lb / 14,000 kg |
| Spindle nose to table | 4.9 in / 124 mm |
| Table T-slots | 9 x 0.87 in / 9 x 22 mm |
| Distance between columns | 99.6 in / 2,530 mm |
| X-axis | 126 in / 3,200 mm |
| Y-axis | 102.4 in / 2,600 mm |
| Z-axis | 36.2 in / 920 mm |
| Maximum spindle speed | 6,000 rpm |
| Spindle power (30 min / continuous) | (10 MIN) 64 hp (48 kW) / 51 hp (38 kW) @ 1180 rpm |
| Spindle torque (30 min / continuous) | (10 MIN) 338 ft. lbs (458 Nm) / 226 ft. lbs (306 Nm) @ 1000 rpm |
| Tool type | CAT 50 |
| Tool capacity | 40 |
| Maximum tool diameter | 4.9 in / 125 mm |
| Maximum tool length | 11.8 in / 300 mm |
| Maximum tool weight | 33 lb / 15 kg |
| Tool-to-tool ATC time | 5 sec |
| Rapid traverse XYZ per minute | XY = 591 in / 15 m Z = 394 in / 10 m |
| Programmable feedrate / minute | 394 in / 10 m unlimited* |
| Maximum operating floor space (W x D x H) | 408.8 x 249.7 x 186.0 in / 10,384 x 6,341 x 4,724 mm |
| Machine weight | 81,439 lb / 37,000 kg |
