HURCO DCX22i-50T CNC Machine Specifications
Origin: Germany
Category: Milling CNC Vertical Machining Center Double Column
| Model | DCX22i-50T |
|---|---|
| Table size | 82.7 x 63 in / 2,100 x 1,600 mm |
| Maximum weight on table | 17,600 lb / 8,000 kg |
| Spindle nose to table | 6 in / 152 mm |
| Table T-slots | 9 x 0.87 in / 9 x 22 mm |
| Distance between columns | 68.9 in / 1,750 mm |
| X-axis | 86.6 in / 2,200 mm |
| Y-axis | 66.9 in / 1,700 mm |
| Z-axis | 29.5 in / 750 mm |
| Maximum spindle speed | 8,000 rpm |
| Spindle power (30 min / continuous) | 30 hp (22 kW) / 20 hp (15 kW) @ 780 rpm |
| Spindle torque (30 min / continuous) | 229 ft. lbs (310 Nm) / 135 ft. lbs (182 Nm) @ 688 rpm |
| Tool type | CAT 50 |
| Tool capacity | 40 |
| Maximum tool diameter | 4.9 in / 125 mm |
| Maximum tool length | 11.8 in / 300 mm |
| Maximum tool weight | 33 lb / 15 kg |
| Tool-to-tool ATC time | 5 sec |
| Rapid traverse XYZ per minute | XYZ = 945 in / 24 m |
| Programmable feedrate / minute | 945 in / 24 m unlimited* |
| Maximum operating floor space (W x D x H) | 259.5 x 237.4 x 152.6 in / 6,591 x 6,031 x 3,875 mm |
| Machine weight | 45,122 lb / 21,000 kg |
