HURCO DCX22i CNC Machine Specifications
Origin: Germany
Category: Milling CNC Vertical Machining Center
| Model | DCX22i |
|---|---|
| Table size | 82.7 x 63 in / 2,100 x 1,600 mm |
| Maximum weight on table | 13,228 lb / 6,000 kg |
| Spindle nose to table | 6 in / 152 mm |
| Table T-slots | 9 x 0.87 in / 9 x 22 mm |
| Distance between columns | 68.9 in / 1,750 mm |
| X-axis | 86.6 in / 2,200 mm |
| Y-axis | 66.9 in / 1,700 mm |
| Z-axis | 29.5 in / 750 mm |
| Maximum spindle speed | 12,000 rpm |
| Spindle power (30 min / continuous) | 20 hp (15 kW) / 15 hp (11 kW) @ 900 rpm |
| Spindle torque (30 min / continuous) | 146 ft. lbs (198 Nm) / 87.5 ft. lbs (119 Nm) @ 720 rpm |
| Tool type | CAT 40 |
| Tool capacity | 40 |
| Maximum tool diameter | 2.95 in / 75 mm |
| Maximum tool length | 11.8 in / 300 mm |
| Maximum tool weight | 15.4 lb / 7 kg |
| Tool-to-tool ATC time | 5 sec |
| Rapid traverse XYZ per minute | XYZ = 945 in / 24 m |
| Programmable feedrate / minute | 945 in / 24 m unlimited* |
| Maximum operating floor space (W x D x H) | 283.9 x 226.9 x 153.1 in / 7,210 x 5,765 x 3,889 mm |
| Machine weight | 44,000 lb / 21,000 kg |
