HURCO BX40i CNC Machine Specifications
Origin: Germany
Category: Milling CNC Vertical Machining Center Double Column
| Model | BX40i |
|---|---|
| Table size | 41.3 x 27.6 in / 1,050 x 700 mm |
| Table T-slots | 6 x 0.7 in / 6 x 18 mm |
| Maximum weight on table | 2,204 lbs / 1,000 kg |
| Spindle nose to table | 7 in / 178 mm |
| X-axis | 40.2 in / 1,020 mm |
| Y-axis | 27.6 in / 700 mm |
| Z-axis | 19.7 in / 500 mm |
| Maximum spindle speed | 20,000 rpm |
| Spindle power (30 min / continuous) | 38.9 hp (29 kW) / 33.5 hp (25 kW) @ 2870 rpm |
| Spindle torque (30 min / continuous) | 73.2 ft. lbs (99.3 Nm) / 61.4 ft. lbs (83.2 Nm) @ 2790 rpm |
| Tool type | HSK 63A |
| Tool capacity | 30 |
| Maximum tool diameter | 3.15 in / 80 mm |
| Maximum tool length | 11.8 in / 300 mm |
| Maximum tool weight | 15.4 lb / 7 kg |
| Tool-to-tool ATC time | 1.5 sec |
| Rapid traverse XYZ per minute | X=1417 in / 36 m Y=1417 in / 36 m Z=1417 in / 36 m |
| Programmable feedrate | 1417 in / 36 m per minute |
| Maximum operating floor space (W x D x H) | 159.4 x 109.3 x 112.8 in / 4,048 x 3,485 x 2,865 mm |
| Machine weight | 20,062 lb / 9,100 kg |
