HURCO BX60i CNC Machine Specifications
Origin: Germany
| Model | BX60i |
|---|---|
| Table size | 74.8 x 51.2 in / 1,900 x 1,300 mm |
| Table T-slots | 8 x 0.87 in / 8 x 22 mm |
| Maximum weight on table | 13,200 lbs / 6,000 kg |
| Spindle nose to table | 7.1 in / 180 mm |
| X-axis | 63 in / 1,600 mm |
| Y-axis | 51.2 in / 1,300 mm |
| Z-axis | 27.6 in / 700 mm |
| Maximum spindle speed | 20,000 rpm |
| Spindle power (30 min / continuous) | 38.9 hp (29 kW) / 33.5 hp (25 kW) @ 2870 rpm |
| Spindle torque (30 min / continuous) | 73.2 ft. lbs (99.3 Nm) / 61.4 ft. lbs (83.2 Nm) @ 2790 rpm |
| Tool type | HSK 64A |
| Tool capacity | 40 |
| Maximum tool diameter | 3.15 in / 80 mm |
| Maximum tool length | 11.8 in / 300 mm |
| Maximum tool weight | 15.4 lb / 7 kg |
| Tool-to-tool ATC time | 1.5 sec |
| Rapid traverse XYZ per minute | X=1417 in / 36 m Y=1417 in / 36 m Z=1417 in / 36 m |
| Programmable feedrate | 1417 in / 36 m per minute |
| Maximum operating floor space (W x D x H) | 212.5 x 206.9 x 149.6 in / 5,398 x 5,256 x 3,800 mm |
| Machine weight | 44,000 lb / 20,000 kg |
