HURCO TM12i CNC Machine Specifications
Origin: Germany
Category: Lathe CNC Turning Milling Center
| Model | TM12i |
|---|---|
| Distance Between Centers | 39.6 in / 1006 mm |
| Swing Over Bed Diameter | 26.77 in / 680 mm |
| Swing Over Cross Slide Diameter | 20.1 in / 510 mm |
| Maximum Turning Diameter | 20.1 in / 510 mm |
| Maximum Turning Length | 39.4 in / 1000 mm |
| Maximum Bar Capacity | 4 in / 102 mm |
| X-Axis | 12 in / 305 mm |
| Z-Axis | 40 in / 1016 mm |
| Maximum Speed High Gear | 2,800 rpm |
| Spindle Power (30 min / Continuous) | 53.64 hp (40 kW) / 40.23 hp (30 kW) @ 868 rpm |
| Spindle Torque (30 min / Continuous) | 324.49 ft. lbs (439.9 Nm) / 243.37 ft. lbs (329.9 Nm) @ 868 rpm |
| Spindle Nose | A2-11 |
| Chuck Diameter | 12.0 in / 315 mm |
| Tool Type | Slotted Disc |
| Tool Capacity | 12 stations |
| Tool Shank | 1 x 1 in / 25 x 25 mm |
| Maximum Boring Bar Diameter | 1.5 in / 40 mm |
| Rapid Traverse X-Axis | 1,181 in / 30 m per min |
| Rapid Traverse Z-Axis | 1,181 in / 30 m per min |
| Maximum Operating Floor Space (W x D x H) | 238.98 x 141.4 x 90.73 in / 6,070 x 3,592 x 2,305 mm |
| Machine Weight | 16,535 lb / 6,686 kg |
