MATSUURA H.Plus-504 CNC Machine Specifications
Origin: Japan
Category: Milling CNC Horizontal Machining Center
| Technical Data | ||
|---|---|---|
| Max Work Size | Φ800 × H1,000 (Φ31.49 × H39.37) | |
| Working Surface | 500 × 500 mm (19.68 × 19.68) | |
| Loading Capacity | 750 kg (1,650 lb) | |
| Tool Taper | CAT #50 / BT – Standard HSK-A100 – Option | |
| Number of Tools | 60 : BT40 – Standard 61 : BT40 – Option 120 / 150 / 180 / 210 / 240 : BT40 – Option 164 / 204 / 244 / 294 : BT40 – Option 120 / 160 / 200 / 240 / 280 / 330 : BT40 – Option | |
| Number of Pallets | 2 – Standard 6 – Floor Pallet System – Option | |
| Spindle Speed | 12,000 RPM : BT40 – Standard 15,000 RPM : BT40 – Option 20,000 RPM : BT40 – Option | |
| Travel (X/Y/Z) | 1,050 / 920 / 990 mm (41.33 / 36.22 / 38.97) | |
| Rapid Traverse (X/Y/Z) | 60 m/min (2,362.20 ipm) | |
| NC System | Matsuura G-Tech 31i | |
| Industries | Automotive and High Performance | |
