MATSUURA H.Plus-405 CNC Machine Specifications
Origin: Japan
Category: Milling CNC Horizontal Machining Center
| Specification | Value |
|---|---|
| Max Work Size | Φ700 × H850 (Φ27.55 × H33.46) |
| Working Surface | 500 × 500 mm (19.68 × 19.68 in) |
| Loading Capacity | 400 kg (880 lb) |
| Tool Taper | CAT #40 / BT - Standard |
| Number of Tools | 60 : BT40 - Standard 71 : BT40 - Option 120/150/180/210/240 : BT40 - Option 120/160/200/240/280/330 : BT40 - Option 360/400/440/480/520 : BT40 - Option |
| Number of Pallets | 2 - Standard 6 : Floor Pallet System - Option 12 : Tower Pallet System - Option |
| Spindle Speed | 12,000 RPM : BT40 - Standard 20,000 RPM : BT40 - Option 30,000 RPM : BT40 - Option |
| Travel (X/Y/Z) | 660 mm (25.98 in) |
| Rapid Traverse (X/Y/Z) | 60 m/min (2,362.20 ipm) |
| NC System | Matsuura G-Tech 31i |
| Industries | Automotive and High Performance |
