MATSUURA LF-160 CNC Machine Specifications
Origin: Japan
Category: Milling CNC Vertical Machining Center 5 Axes
| Max Work Size (mm / in) | Φ160 × H230 (Φ6.29 × H9.05) - Standard Φ160 × H200 (Φ6.29 × H7.87) - with PC |
|---|---|
| Working Surface (mm / in) | Φ100 (Φ3.93) - Standard Φ112 (Φ4.40) - with PC |
| Loading Capacity (kg / lb) | 20 (44) |
| Number of Tools | 10 : BT30 - Standard, 30/50 : BT30 - Option, 128 / 188 / 248 / 308 / 338 : BT30 - Option, 10 : HSK-E40 - Standard, 30/50 : HSK-E40 - Option, 128 / 188 / 248 / 308 / 338 : HSK-E40 - Option |
| Number of Pallets | Fixed Table - Standard 2 - Option 42 : Linear Pallet System - Option 91 : Linear Pallet System - Option |
| Spindle Speed (RPM) | 46,000 : BT30 - Standard 46,000 : HSK-E40 - Option |
| Travel (X/Y/Z) (mm / in) | 500 / 250 / 300 (19.68 / 9.84 / 11.81) |
| Travel (B/C) (°) | -125 ~ +125 / 360 |
| Rapid Traverse (X/Y/Z) (m/min / ipm) | 90 (3,543.30) |
| Rapid Traverse (B/C) (min⁻¹) | 100 / 200 |
| NC System | Matsuura G-Tech 31i |
| Industries | Die / Mold |
