TAKAMAZ TAKAMATSU MACHINERY XTL-8MY CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Turning Center
| Item | Ability | Unit |
|---|---|---|
| Chuck size | Collet, 8 | inch |
| Spindle | Spindle bearing I.D. | φ100 mm |
| Spindle speed | Max. 4,000 | min-1 |
| Tool post | Type | 12-station turret |
| Max. stroke | X:175 Z:550 Y:+35, -40 | mm |
| Rapid traverse rate | X:18 Z:24 Y:10 | m/min |
| Power tool – Tool storage capacity | 12 | pcs. |
| Power tool – Rotation speed | 4,000 | min-1 |
| Capacity | φ20 / M16 | mm |
| Spindle motor | AC15 / 11 | kW |
| W × L | Manual machine: 2,410 (1,840※1) × 1,930 Machine with loader: 2,410 (1,840※1) × 1,930 | mm |
| Controller | TAKAMAZ & FANUC 0i-TF Plus | |
| ※1 Bed width | ||
| Item【Loader specifications】 | ||
| Type | FGH (FANUC) ※1 | |
| Workpiece diameter (Reference) | φ75 | mm |
| Workpiece length (Reference) | 500 | mm |
| Max. load capacity | 5 | kg |
| Rapid traverse rate | Y:160 Z:160 | m/min |
| ※ The length depends on the workpiece diameter. If the workpiece weighs more than the above, it cannot be loaded, even within the size range described. ※1 Some machine operation switches and loader operation switches are of the touch-screen type. (Subject to change without prior notice.) | ||
