TAKAMAZ TAKAMATSU MACHINERY J-WAVE PLUS CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Gang Type 4 Inch
| Item | Ability | Unit |
|---|---|---|
| Chuck size | Collet, 4 | inch |
| Spindle bearing I.D. | φ65 | mm |
| Spindle speed | Max. 4,500 | min⁻¹ |
| Tool post type | Gang type | - |
| Max. stroke | X: 200 / Z: 250 | mm |
| Rapid traverse rate | X: 18 / Z: 18 | m/min |
| Spindle motor | AC 5.5 / 3.7 | kW |
| Machine size (W × L) | 1,506 × 1,250 | mm |
| Controller | TAKAMAZ & MITSUBISHI M80 | - |
| Item 【Loader specifications】 | Ability | Unit |
|---|---|---|
| Model | WA30 | - |
| Workpiece diameter (Reference) | φ30 | mm |
| Workpiece length (Reference) | 50 | mm |
| Max. load capacity | 0.3 | kg |
| Rapid traverse rate | Z: 75 | m/min |
