TAKAMAZ TAKAMATSU MACHINERY XT-6M CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Turning Center
| Item | Ability | Unit |
|---|---|---|
| Chuck size | Collet, 6 | inch |
| Spindle – Spindle bearing I.D. | φ75 | mm |
| Spindle speed | Max. 4,500 (6,000 Opt.) | min-1 |
| Tool post – Type | 12-station turret | |
| Max. stroke | X:120 Z:265 | mm |
| Rapid traverse rate | X:18 Z:24 | m/min |
| Power tools – Tool storage capacity | 6 | pcs. |
| Power tools – Rotation speed | 4,000 | min-1 |
| Capabilities | φ10 / M6 | mm |
| Spindle motor | AC7.5 / 5.5 | kW |
| W × L | 1,360 × 1,370 | mm |
| Controller | TAKAMAZ & FANUC 0i-TF Plus | |
| Item【Loader specifications】 | ||
| Loader Types | ΣiC60 / FC60※1 / ΣiGH80 / ΣiGH80 (Hi speed type) / FGH※1 | |
| Workpiece diameter (Reference) | φ60 / φ80 | mm |
| Workpiece length (Reference) | 50 / 60 | mm |
| Max. load capacity | 1.0 / 1.5 | kg |
| Rapid traverse rate | ΣiC60: Y:71 Z:84 FC60: Y:120 Z:120 ΣiGH80: Y:125 Z:155 ΣiGH80 (Hi speed): Y:200 Z:190 FGH: Y:160 Z:160 | m/min |
| ※ The length depends on the workpiece diameter. If the workpiece weighs more than the above, it cannot be loaded. ※ With the FANUC loader specification, the NC unit is installed with a touch-panel screen and Windows PC. | ||
