TAKAMAZ TAKAMATSU MACHINERY XTL-8 CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Turning Center
| Item | Ability | Unit |
|---|---|---|
| 8-station turret (Standard) | 12-station turret (Option) | |
| Chuck size | Collet, 8 (10 Opt.) | inch |
| Spindle – Spindle bearing I.D. | φ100 (φ120 Opt.) | mm |
| Spindle speed | Max. 4,000 (5,000・3,000 Opt.) | min-1 |
| Tool post – Type | 8-station turret 12-station turret | |
| Max. stroke | X:190 Z:600 | mm |
| Rapid traverse rate | X:18 Z:24 | m/min |
| Spindle motor | AC15/11 : φ100 4,000 min⁻¹ (AC15/11 : φ100 5,000 min⁻¹ Opt.) (AC15/11 : φ120 3,000 min⁻¹ Opt.) | kW |
| W × L | 1,840 × 1,860 | mm |
| Controller | TAKAMAZ & FANUC 0i-TF Plus | |
| Item【Loader specifications】 | ||
| Type | FGH (FANUC) ※1 | |
| Workpiece diameter (Reference) | φ75 | mm |
| Workpiece length (Reference) | 450 | mm |
| Max. load capacity | 5 | kg |
| Rapid traverse rate | Y:160 Z:160 | m/min |
| ※ The length depends on the workpiece diameter. If the workpiece weighs more than the above, it cannot be loaded, even within the size range described. ※1 Some machine operation switches, and the loader operation switches, are of the touch-screen type. (Subject to change without prior notice.) | ||
