SKODA SUT 200 TD x 35000 Heavy-Duty Lathe 35 Meters Between Centers – Year 1984
| Specification | Metric | Imperial |
|---|---|---|
| Distance Between Centers | 35,000 mm | 1,378 in (114.8 ft) |
| Max Turning Diameter | 2,020 mm | 79.5 in |
| Swing Over Cross Slide | 1,600 mm | 63 in |
| Max Workpiece Weight | 63,000 kg | 138,900 lbs |
| Spindle Motor Power | 2 × 82 kW | 2 × 110 hp |
| Total Installed Power | 2 × 150 kW | 2 × 201 hp |
| Overhauled | No | No |
| Tailstock | Yes (2 units) | Yes |
| Steady Rest | Yes (5 + 2 units) | Yes |
| Travelling Rest | 6 units | 6 units |
| Cross Slide | 2 × Double | 2 × Double |
| Chuck Type | 4-Jaw | 4-Jaw |
| Chuck Size | 2 × 2000 mm | 2 × 79 in |
| Machine Condition | Needs Rebuild (New Control Required) | Needs Rebuild |
| Machine Dimensions (L × W × H) | 45,200 × 3,500 × 3,000 mm | 1,780 × 138 × 118 in |
| Machine Weight | 150,000 kg | 330,700 lbs (165 tons) |
