Gray Vertical Boring Mill VTL 60 inch – Year 2006

GENERAL SPECIFICATIONS
CONTROL: FANUC 18ITT CNC 4-AXIS
TABLE DIAMETER: 70”
MAXIMUM SWING: 74”
MAX TABLE WEIGHT: 40,000 LBS.
MAXIMUM HEIGHT UNDER RAIL: 70”
SPINDLE SPEED: 1.1 – 228 RPM SPINDLE SPEED
MOTOR: 75 HP
MACHINE FLOOR SPACE: 14’ W X 14’ L X 20’ H
MACHINE WEIGHT: 75,000 LBS
INCLUDES: COMPLETE WITH RS-232 INTERFACE, 40,000 LBS. TABLE CAPACITY,4-JAW COMBINATION MANUAL CHUCK, CHIP GUARDS, FANUC DRIVES, MANUALS AND QUICK CHANGE SANDVIK TOOLING, 2 RAM HEADS

4 AXIS, DUAL RAM VTL WITH A 70” TABLE AND 74” SWING. THE TABLE CAN HANDLE UP TO A 40,000 POUND PART WITH A 75 HP SPINDLE MOTOR AND A MAX. SPEED OF 228 RPM.
