In Stock & Available For Sale : used Akyapak AHS 30/60 Sheet & Plate Bending Rolls 4 Rolls- Year 2013 made in Türkiye / REQUEST MACHINE INSPECTION
| Akyapak AHS 30/60 Sheet & Plate Bending Rolls 4 Rolls- Year 2013 | ||
|---|---|---|
| Specification | Metric | Imperial |
| General Information | ||
| Manufacturer | Akyapak | |
| Model | AHS 30/60 | |
| Year | 2013 | |
| Machine Type | Hydraulic 4-Roll Plate Rolling Machine | |
| Number of Rolls | 4 Rolls | |
| Bending Capacity | ||
| Working Length | 3,100 mm | 122.05 in |
| Maximum Plate Thickness | 73 mm | 2.87 in |
| Pre-Bending Capacity | 60 mm | 2.36 in |
| Minimum Bending Diameter | 3,050 mm | 120.08 in |
| Minimum Bending Diameter Formula | Top Roll Diameter × 5 | |
| Roll Diameters | ||
| Top Roll Diameter | 610 mm | 24.02 in |
| Bottom Roll Diameter | 550 mm | 21.65 in |
| Side Roll Diameter | 460 mm | 18.11 in |
| Motor | ||
| Motor Power | 75 kW | Approx. 100.6 HP |
| Machine Dimensions | ||
| Length | 6,750 mm | 265.75 in / 22.15 ft |
| Height | 3,470 mm | 136.61 in / 11.38 ft |
| Width | 3,000 mm | 118.11 in / 9.84 ft |
| Overall Dimensions (L × W × H) | 6,750 × 3,000 × 3,470 mm | 265.75 × 118.11 × 136.61 in |
| Weight | ||
| Machine Weight | 51,200 kg | Approx. 112,877 lb |
| Technical Notes | ||
| Capacity Reference | Specifications are based on steel with a yield point of 240 N/mm². | |
| Cone Bending | For cone bending capacities, half of the stated bending capacities should be considered. | |
| Manufacturer’s Note | Akyapak reserves the right to change the specifications without prior notice. | |
