AWEA AF-1000 CNC Machine Specifications
Origin: Taiwan
Category: Milling CNC Vertical Machining Center
| Specification | AF-1000 |
|---|---|
| X-axis travel | 1,020 mm |
| Y-axis travel | 550 mm |
| Z-axis travel | 635 mm |
| Distance from spindle center to column | 588 mm |
| Distance from spindle nose to table top | 100 – 735 mm |
| Table size (X direction) | 1,200 mm |
| Table size (Y direction) | 550 mm |
| Table load capacity | 700 kg |
| T-slot (Width × Pitch × No.) | 18 mm × 100 mm × 5 |
| Spindle taper | BT40 |
| Spindle motor (cont. / 30 min.) | 11 / 15 kW |
| Spindle speed | Direct-drive 12,000 rpm |
| X / Y axes rapid feed rate | 36 m/min |
| Z-axis rapid feed rate | 24 m/min |
| Cutting feed rate | 15 m/min |
| Tool magazine capacity | 24 T |
| Max. tool length | 250 mm |
| Max. tool weight | 7 kg |
| Max. tool diameter / adj. pocket empty | Ø 75 / Ø 150 mm |
| Positioning accuracy (ISO 230-2) | 0.006 mm |
| Repeatability (ISO 230-2) | 0.005 mm |
| Control system | FANUC Oi-MF PLUS |
| Pneumatic pressure requirement | 6 kg/cm² |
| Power requirement | 30 kVA |
| Coolant tank capacity | 360 liters |
| Machine weight | 7,000 kg |
