Scledum RG-270 Crankshaft Grinding Machine 2 Meters – Year 1980
Specification	Metric	Imperial
Manufacturer	Scledum	Scledum
Model	RG-270	RG-270
Year of Manufacture	1980	1980
Machine Type	Crankshaft Grinding Machine	Crankshaft Grinding Machine
Application	Precision Grinding of Crankshafts, Shafts and Eccentric Rotating Components	Precision Grinding of Crankshafts, Shafts and Eccentric Rotating Components
Center Distance	2,000 mm	78.74 in
Maximum Turning Radius	270 – 275 mm	10.63 – 10.83 in
Machinable Components	Crankshafts, Shafts, Eccentric Rotating Parts	Crankshafts, Shafts, Eccentric Rotating Parts
Machine Bed	Heavy-Duty Cast Iron Construction	Heavy-Duty Cast Iron Construction
Guideway System	Precision Ground Guideways	Precision Ground Guideways
Grinding Spindle	High-Rigidity Bearing Design	High-Rigidity Bearing Design
Feed System	Fine Feed Cross and Longitudinal Slide System	Fine Feed Cross and Longitudinal Slide System
Positioning System	Manual Feed and Positioning Control	Manual Feed and Positioning Control
Workpiece Support	Adjustable Bearing Support System for Long Workpieces	Adjustable Bearing Support System for Long Workpieces
Machine Structure	Vibration-Damped Industrial Frame	Vibration-Damped Industrial Frame
Motor Type	High-Performance Grinding Motor	High-Performance Grinding Motor
Operating Duty	Continuous Industrial Operation	Continuous Industrial Operation
Coolant System	Coolant Preparation and Connection Points Included	Coolant Preparation and Connection Points Included
Design Characteristics	Heavy-Duty Industrial Design for Long Service Life	Heavy-Duty Industrial Design for Long Service Life
Included Accessories & Equipment
Main & Tailstock System	Included	Included
Grinding Spindle Unit	Included with Grinding Wheel Mounting	Included with Grinding Wheel Mounting
Adjustable Bearing Supports	Included	Included
Workpiece Clamping System	Included	Included
Precision Adjustment & Centering Elements	Included	Included
Grinding Wheel Mounting Flanges	Included	Included
Workpiece Rotation Mechanism	Included	Included
Control Panel	Handwheel-Controlled	Handwheel-Controlled
Slide System	Complete Fine-Feed Slide System	Complete Fine-Feed Slide System
Machine Bed & Frame	Complete Industrial Machine Body	Complete Industrial Machine Body
Adjustable Workpiece Supports	Included	Included

General Terms of Sale Inspection and Condition All machines are offered in used condition. We strongly recommend that buyers personally inspect and test the equipment at our premises prior to purchase. Unless otherwise agreed in writing, all machines are sold “as is, where is”, without any warranty or guarantee. Loading, Transportation and Risk The buyer is solely responsible for all costs and risks associated with loading, transportation, freight, insurance, securing, and delivery of the machine. Responsibility transfers to the buyer upon collection/loading. Payment Terms The machine may only be released and collected after the full purchase price has been received and cleared in our bank account. Cash payments may be accepted within applicable legal limits and regulations.
