Description
FAT TUR 630 MN – Year 2002
| Ø above the bed | 650 mm |
|---|---|
| Ø above transversing slide | 300 mm |
| Length between centers | 1000 mm |
| Type of CNC | Siemens |
| Spindle bore | 105 mm |
| Turning speed | 2500 rpm |
| Tailstock | no |
| Bar feeder | no |
| Length x width x height | 4000.0 × 2300.0 × 1760.0 |
| Weight | 4500 kg |
FAT TUR 630MN
Brand: FAT (Poreba)
Type: 630 MN
Cn: Siemens
Year: 2002
Chuck diameter: 500 mm
Diameter on bench: 650 mm
Diameter on trolley: 300 mm
Distance between centers: 1000 mm
Spindle passage: 105 mm
Spindle: 2500 rpm
Gearbox: 5-430, 115-2500
