TRUMPF TruLaser 3040 Bevel Cut CNC Machine Specifications
Origin: Germany
Category: Laser Cutting 2D
| Specification | TruLaser 3040 Bevel Cut |
|---|---|
| Maximum Speed | |
| Simultaneous | 170 m/min |
| Working Range | |
| X axis | 4,002 mm |
| X axis (50° bevel cut) | 3,355 mm |
| Y axis | 2,099 mm |
| Y axis (50° bevel cut) | 1,600 mm |
| Laser Data – TruFiber 12001 | |
| Maximum laser power | 12,000 W |
| Max. sheet thickness – mild steel | 30 mm (35 mm w/ package) |
| Max. sheet thickness – mild steel (50° bevel) | 15 mm |
| Max. sheet thickness – stainless steel | 40 mm (50 mm w/ package) |
| Max. sheet thickness – stainless steel (50° bevel) | 10 mm |
| Max. sheet thickness – aluminum | 30 mm |
| Max. sheet thickness – copper | 12.7 mm |
| Max. sheet thickness – brass | 12.7 mm |
| Consumption | |
| Avg. power input – TruFiber 12001 | 16 kW |
