TAKISAWA TS-5000Y CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Turning Center
| TS-5000Y | ||
|---|---|---|
| Right Spindle Stock | - | |
| Tailstock (NC Servo Type) | ● | |
| Chuck Size | inch | 12 |
| Type of Turret | 12-Station Turret (All-Holder Type) Standard 10-Station Turret (All-Holder Type) 15-Station Turret (All-Holder Type) 20-Station Turret (All-Holder Type) | |
| Max. Turning Diameter | mm | ⌀370 ⌀315 ⌀292 |
| Max. Turning Length | mm | 1300 1285 1300 |
| Bar Capacity *1 | mm | ⌀102 [OP. ⌀82] |
| Left Spindle Speed | min⁻¹ | 2500 [OP. 4200] |
| Right Spindle Speed | min⁻¹ | - |
| Rotary Tool Speed | min⁻¹ | 6000 |
| Rapid Traverse Rate | m/min | X : 30 / Z : 30 / Y : 10 / A : 13 |
| Left Spindle Motor (30 min/continuous) | kW | 22/15 |
| Right Spindle Motor (30 min/continuous) | kW | - |
| Rotary Tool Motor (S3 25%/continuous) | kW | 7.5/3.7 |
| Machine Height | mm | 2300 |
| Required Floor Space | mm | 4105×2255 *2 |
| Machine Weight | kg | 8500 |
| ●: Standard – : None *1) Please note the bar capacity follows types of chucks and cylinders. *2) Without Oilpan and Chip Conveyor. | ||
