TAKISAWA TK-2100 CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Vertical 8 Inch
| Chuck Size | inch | 8 | ||
| Type of Turret | Comb Type Tool Slide | 6-Station Turret (Direct-Mount Type) | 8-Station Turret (Direct-Mount Type) | |
| Max. Swing | mm | 400 《600》 | ||
| Max. Turning Diameter | mm | - | φ355 | φ335 |
| Max. Turning Length | mm | 400 | 310 | |
| Spindle Speed | min⁻¹ | 3200 [OP. 2000, 2500] | ||
| Rapid Traverse Rate | m/min | X : 20 / Z : 20 | ||
| Spindle Motor (30 min/continuous) | kW | 11/9 [OP. 15/11, 18.5/15] | ||
| Machine Height | mm | 2200 | ||
| Required Floor Space | mm | 1220×1980 《1600×1980》 | ||
| Machine Weight | kg | 3600 | 3700 |
