TAKISAWA TCC-1100 CNC Machine Specifications
Origin: Japan
Category: Lathe CNC 6 Inch
| Specification | Unit | Value | |
|---|---|---|---|
| Chuck Size | inch | 6 | |
| Type of Turret | 8-Station Turret (Direct-Mount Type) | 12-Station Turret (Direct-Mount Type) | |
| Max. Turning Diameter | mm | φ220 | φ170 |
| Max. Turning Length | mm | 171 | |
| Bar Capacity*1 | mm | φ42 | |
| Spindle Speed | min⁻¹ | 4000 [Optional: 5000, 6000] | |
| Rapid Traverse Rate | m/min | X : 24 / Z : 30 | |
| Spindle Motor (15/30 min - Continuous) | kW | 5.5 / 3.7 [Optional: 7.5 / 5.5] | |
| Machine Height | mm | 1700 | |
| Required Floor Space | mm | 1200 × 1370 | |
| Machine Weight | kg | 1860 | |
