PRIMERO AMD650 CNC Machine Specifications
Origin: Taiwan
Category: Milling CNC Vertical Machining Center 5 Axes
| AMD650 Specifications | |
|---|---|
| WORKTABLE | |
| Workbench panel size | 750 × 500 mm |
| Maximum machining range | - |
| Maximum load-bearing capacity | 300 kg |
| TRAVEL | |
| X-axis travel | 650 mm |
| Y-axis travel | 500 mm |
| Z-axis travel | 380 mm |
| A-axis travel | - |
| C-axis travel | - |
| SPINDLE | |
| Spindle speed | 20000 rpm |
| Fast feed | 36 M/min |
| Cutting feed | 36 M/min |
| TOOL MAGAZINE | |
| Number of tools | 40 tools (optionally expanded to 140 tools) |
| POSITIONING ACCURACY | |
| Positioning accuracy | ±0.004 mm |
| Linear axial positioning accuracy | - |
| Rotary axial positioning accuracy | ±0.002 mm |
| Linear axial repeated positioning accuracy | - |
| ACCURACY | |
| Accuracy | 1.2 G |
| MACHINE LAYOUT | |
| Footprint | 1,700 × 2,750 mm |
| Machine weight | 6,200 kg |
Standard Accessories:
- DDR cradle-type dual-axis rotating workbench / water-cooled
- Automatic tool changing system - with 40 tools
- Controller system: NUM Flexium Plus 68 (23.8\" touch LCD, HSC function, RTCP)
- Intelligent assistance system for ICS
- Contact tool setter
- Fully-enclosed outer shell sheet metal
- Central cooling system
- Three-axis hollow cooling screw
- Servo hydraulic system
- Central lubrication system
- Auxiliary water tank
- Cutting fluid precision filtration system
- Chip collection box
- Water pump
- Electrical cabinet air conditioning
- Work light
- Three-layer warning light
- Foundation screws and pads
- Toolbox
- Mechanical components: 1-year warranty
- Controller: 2-year warranty
Optional Accessories:
- Siemens 828 / Siemens ONE controller
- Electric spindle / 30000 RPM / HSK-E40
- Internal visual monitoring system
- Three-axis optical ruler (HEIDENHAIN 0.01 µm resolution)
- Visual tool setter
- High-capacity tool magazine (100 tools)
- Oil-water separator
- Oil mist recovery device
- Automatic door
- Chain plate type chip conveyor
- Chip trolley
- High-accuracy contact CNC probe
- Centering precision vices
- Bottom plates for centering precision vices
