PARA MILL PRECISION MACHINERY HM-2250DS-1000 CNC Machine Specifications
Origin: Taiwan
Category: Milling
| Cutting capacity | No. of control spindle | 4 |
| Cutting size Min. / Max. | 500 / 1000 mm | |
| Max. cutting thickness (Cutter) | 300 mm | |
| Spindle box & spindle | Distance between spindle nose | 600 ~ 1200 mm |
| Spindle motor | 20 HP (15 kW) | |
| Spindle taper | NT–50 | |
| Spindle speed (variable) | 50 ~ 900 rpm | |
| Z / X / Y / A Axes | Max. longitudinal travel (Z-axis) | 2250 mm |
| Max. spindle travel (X, Y-axes) | 310 mm | |
| Servo motor (Z, A-axes) | 2.9 kW | |
| Servo motor (X, Y-axes) | 2 kW | |
| Dia. of ball screw (Z-axis) | Φ63 P12 | |
| Dia. of ball screw (X, Y-axis) | Φ40 P10 | |
| Rapid feed (Z-axis) | 6 m/min | |
| Rapid feed (X, Y-axis) | 6 m/min | |
| Work table | Worktable area | 920 x 2300 mm |
| Index table | Dimensions | 800 x 800 mm |
| Max. load | 4000 kg | |
| Oil tank capacity | Hydraulic unit | 100 L |
| Lubrication oil tank | 2 L x 3 | |
| Others | Machine dimension (W x L x H) | 4100 x 6500 x 2550 mm |
| N.W. | 16 tons |
