MTP CNC 500L CNC Vertical Machining Center MTP CNC 500L CNC Vertical Machining Center

Machine Type	MTP CNC 500L CNC Vertical Machining Center
X-axis Travel	600 mm
Y-axis Travel	400 mm
Z-axis Travel	450 mm
Distance from Guideway to Spindle Center	100 – 550 mm
Table Size	800 × 320 mm
T-Slots	3 × 16 × 75 mm
Maximum Table Load	300 kg
Spindle Taper	BT40
Spindle Diameter	Ø120 mm
Spindle Speed Range	1 – 8,000 RPM
Spindle Power	5.5 / 7.5 kW
Rapid Feed Rate (X / Y / Z)	18 / 18 / 16 m/min
Cutting Feed Rate	1 – 8,000 mm/min
Positioning Accuracy	±0.02 mm
Repeatability	±0.02 mm
Automatic Tool Changer (ATC)	Included
Tool Magazine Capacity	12 Tools
Total Power Requirement	15 kVA
Power Supply	400 V / Three-Phase
Machine Dimensions (L × W × H)	2100 × 1750 × 2300 mm
Machine Weight	2600 kg
Standard Equipment	CNC Control System Automatic Tool Changer (12 Positions) Through-Spindle Coolant System Chip Evacuation System Chip Conveyor Full Enclosure with LED Lighting UPS Backup Power Supply for Control System Technical Documentation User Manual
Optional Equipment	4th Rotary Axis 5th Rotary Axis
Warranty & Service	Brand New Machine 12-Month Manufacturer’s Warranty Warranty Service Support Post-Warranty Technical Assistance Spare Parts Availability
Key Features	Vertical CNC Machining Center BT40 Spindle System Spindle Speed up to 8,000 RPM Automatic Tool Changer with 12 Positions High-Precision Linear Guideways Through-Spindle Coolant System Chip Evacuation and Conveyor System Fully Enclosed Machine Design LED Work Area Lighting High Positioning and Repeatability Accuracy Optional 4th and 5th Rotary Axis Suitable for Production and Prototype Machining
Description	The MTP CNC 500L is a modern vertical CNC machining center designed for precision milling, drilling, tapping, and machining of metal and engineering plastic components. Combining a rigid machine structure, high-performance spindle, and automatic tool changing system, this machining center delivers excellent accuracy, reliability, and productivity for both single-part and batch production. Built on a stable machine frame with precision linear guideways, the CNC 500L ensures smooth operation and consistent machining accuracy even during intensive production cycles. The powerful BT40 spindle operating at speeds up to 8,000 RPM provides excellent cutting performance across a wide range of materials including steel, stainless steel, aluminum, brass, bronze, and engineering plastics. The machine is equipped with a 12-position automatic tool changer that significantly reduces setup times and improves production efficiency. Its intuitive CNC control system enables easy programming and operation, making it suitable for both experienced machinists and modern production facilities seeking reliable CNC machining solutions. Additional features such as through-spindle coolant, chip evacuation system, chip conveyor, LED lighting, and a fully enclosed working area enhance operator safety, machine cleanliness, and overall productivity.
