MAZAK HQR-150MSY CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Turning Milling Center 2 Turret 2 Spindle
| Category | Specification | Value |
|---|---|---|
| Universal | Universal type | 600U |
| Spindle | Chuck size | 6 \" |
| Max. spindle speed | 5000 rpm | |
| Max. torque (15%ED) | 172 ft-lbs | |
| Spindle motor (30 min. rating) | 15 kW (20 HP) | |
| Spindle motor (cont. rating) | 11 kW (15 HP) | |
| Chuck size | 6 \" | |
| Second spindle | Max. spindle speed | 6000 rpm |
| Spindle motor (30 min. rating) | 11 kW (15 HP) | |
| Spindle motor (cont. rating) | 7.5 kW (10 HP) | |
| Chuck size | 6 \" | |
| Upper and lower turret | Tool storage capacity | 12 |
| Tool shank height | 1 \" | |
| Boring bar shank diameter | Φ1 \" | |
| Rotary tool spindle | Max. spindle speed | 6000 rpm |
| Max. torque (3 min. rating) | 26 ft-lbs | |
| Spindle motor (10 min. rating) | 5.5 kW (7.5 HP) | |
| Spindle motor (cont. rating) | 2.2 kW (3 HP) | |
| Travel | X-axis (upper turret / lower turret) | 7 \" / 4 \" |
| Y-axis (upper turret / lower turret) | 4\" (±2\") / 4\" (±2\") | |
| Z-axis (upper turret / lower turret) | 20 \" / 23 \" | |
| Rapid traverse rate | X-axis (upper turret / lower turret) | 1181 IPM / 945 IPM |
| Y-axis (upper turret / lower turret) | 1024 IPM / 787 IPM | |
| Z-axis (upper turret / lower turret) | 1575 IPM / 1575 IPM | |
| Machine size | Width × Length (MAZATROL SmoothG) | 113 \" × 91 \" |
| Height | 96 \" | |
| Machine weight | 20326 lbs |
