Warner Swasey WSU-12 CNC Lathe 12 inch – Year 1984
| Year | 1984 |
|---|---|
| Make | Warner Swasey |
| Model | WSU-12 |
| Warner Swasey WSU-12 | CNC Lathe |
| Chuck Size | 12″ |
|---|---|
| Bar Capacity | 3″ |
| Swing | 26″ |
| Turning Diameter | N/A |
| Spindle Speed | 3,000 RPM |
| Control | Fanuc 6-TB |
| Distance Between Centers | 40″ |
| Turret | 8 |
| Chip Removal | Chip Conveyor |
| Spindle Motor | 30 HP |
| Dimensions | 17’3″ x 7’3″ x 7′ |
| Weight | 22,500 Lbs |
Features
| 12″ SP Counter Centrifugal Chuck | Tailstock |
| Low Hours |
| Specification | Imperial | Metric |
|---|---|---|
| Chuck Size (3-Jaw Hydraulic) | 12″ | 304.8 mm |
| Spindle Type | A2-8 | A2-8 |
| Bolt Circle (Outer) | 6.75″ | 171.45 mm |
| Hole Through Spindle | 3.500″ | 88.9 mm |
| Bar Capacity (Round) | 3″ | 76.2 mm |
| Swing Over Cross Slide Block | 15″ | 381 mm |
| Swing Over Telescoping Guard | 26″ | 660.4 mm |
| Main Motor Power | 30 HP | 22 kW |
| Spindle Speed Range | 43 – 3000 RPM | 43 – 3000 RPM |
| Constant HP Range | 435 – 3000 RPM | 435 – 3000 RPM |
| Optional Spindle Speed | 21 – 1800 RPM | 21 – 1800 RPM |
| Optional Constant HP Range | 217 – 1800 RPM | 217 – 1800 RPM |
| Rapid Rate (Cross) | 400 IPM | 10,160 mm/min |
| Rapid Rate (Longitudinal) | 400 IPM | 10,160 mm/min |
| Feed Rate (Cross) | 0.01 – 200 IPM | 0.25 – 5080 mm/min |
| Feed Rate (Longitudinal) | 0.01 – 200 IPM | 0.25 – 5080 mm/min |
| Cutter Size | 1-1/4″ Sq x 5″ | 31.75 mm Sq x 127 mm |
| Turret Tool Stations | 12 | 12 |
| Turret Face Mount | 12 Total | 12 Total |
| Turret Mount | 4 | 4 |
| Cross Stroke | 14.000″ | 355.6 mm |
| Longitudinal Stroke | 42.559″ | 1081 mm |
| Turning Stroke Between Centers | 40″ | 1016 mm |
