MATSUURA MAM72-35V PC32 – Year 2014
CNC 5-axis Machining Centre

Manufacturer : MATSUURA
Model : MAM72-35V PC32
Year of manufacture : 2014

Technical details

z-motion : 580 mm
max. workpiece weight between centers : 60 kg
x-motion : 550 mm
y-motion : 440 mm
control : Matsuura G-Tech 31i
numbers of pallets : 32
taper : BT40
toolchanger positions : 120
turning speed range : 15,000 rpm
rapid motion : 60 m/min
weight approx. : 12,000 kg
dimensions (l x w x h) approx. : 6,025 x 3,200 x 3,200 mm

Machine description

5-Axis Machining Centre
Serial number: 19627
Max. working size: Ø350×H300mm
Travel (X/Y/Z): 550/440/580 mm
Travel (A/C): -125～+65/360°
Working surface: diameter 130 mm
Travel (B/C): -125 ~ +65/360°
Rapid traverse (X/Y/Z): 60/60/60 m/min
Rapid traverse (A/C): 50/100 min-1
Rapid traverse (B/C): 50/100 min-1
Big Plus-Spindle
20 Bar High Pressure coolant Through the Spindle
Tower Pallet System with 32 Pallets incl. Load/Unload Station
Spindle Load Monitoring

including
FSE Chip Management System
Serial number: 19836-15
System capacity: 1250 L
Flowrate: 385 L/min

FilterMist FX 5002

Various tool holders (without tooling)

Dismantling & loading costs (binding) : 6,500.00 €
Total Price : plus VAT

available, under power
