GEMINIS GE1000A Universal Lathe 1.5 Meters

Specification	Metric	Imperial
Machine Type	Heavy Duty Engine Lathe	Heavy Duty Engine Lathe
Make / Model	GEMINIS GE1000A	GEMINIS GE1000A
Center Height	480 mm	18.9 in
Distance Between Centers	1500 mm	59.1 in
Swing in Gap	1300 mm	51.2 in
Max Diameter Over Cross Slide	650 mm	25.6 in
Max Diameter Over Bed	1000 mm	39.4 in
Spindle Bore	104 mm	4.09 in
Cross Slide Stroke	620 mm	24.4 in
Gap Width	450 mm	17.7 in
Tailstock Quill Stroke	300 mm	11.8 in
Small Tool Carriage Stroke	250 mm	9.84 in
Tailstock Taper	CM6 (MT6)	CM6 (MT6)
Bed Width	680 mm	26.8 in
Number of Spindle Speeds	24	24
Spindle Speed Range	4.5 – 900 RPM	4.5 – 900 RPM
Number of Feeds (Longitudinal/Transverse)	154	154
Longitudinal Feed Range	0.04 – 60 mm/rev	0.0016 – 2.36 in/rev
Cross Feed Range	0.02 – 30 mm/rev	0.0008 – 1.18 in/rev
Metric Thread Range	0.4 – 600 mm	0.0157 – 23.6 in
Whitworth Threads	40 – 3/32 TPI	40 – 3/32 TPI
Module Range	0.1 – 150 Module	0.1 – 150 Module
Main Motor Power	22 kW	30 HP
Machine Dimensions (L x W x H)	4000 x 2000 x 1500 mm	157 x 79 x 59 in
Machine Weight	8000 kg	17,637 lbs
