| Specification |
Metric |
Imperial |
| Manufacturer |
Alpha Laser |
Alpha Laser |
| Model |
AL3D Compact Metal (AL3D-METAL 200-100) |
AL3D Compact Metal (AL3D-METAL 200-100) |
| Machine Type |
SLM Metal 3D Printer (Selective Laser Melting) |
SLM Metal 3D Printer (Selective Laser Melting) |
| Year of Manufacture |
2022 |
2022 |
| Condition |
Like New (Used) |
Like New (Used) |
| Functionality |
Fully Functional |
Fully Functional |
| Printing Technology |
Selective Laser Melting (SLM) |
Selective Laser Melting (SLM) |
| Laser Type |
Fiber Laser |
Fiber Laser |
| Laser Wavelength |
1,070 nm |
1,070 nm |
| Laser Power |
200 W |
200 W |
| Laser Operating Mode |
Continuous Wave (CW) |
Continuous Wave (CW) |
| Laser Focus Diameter |
50 μm |
0.00197 in |
| Maximum Scanning Speed |
5 m/s |
196.85 in/s |
| Build Volume |
Ø100 × 60 mm |
Ø3.94 × 2.36 in |
| Number of Build Cartridges |
9 Cartridges Included |
9 Cartridges Included |
| Layer Thickness |
10 – 50 μm |
0.00039 – 0.00197 in |
| Achievable Part Density |
>99% |
>99% |
| Print Material System |
Closed Cartridge Powder Handling System |
Closed Cartridge Powder Handling System |
| Powder Contact |
No Direct Contact During Preparation or Printing |
No Direct Contact During Preparation or Printing |
| Software |
AL3D-OS |
AL3D-OS |
| Operation Interface |
15.6″ Touchscreen, Keyboard & Mouse |
15.6″ Touchscreen, Keyboard & Mouse |
| CAD File Format |
STL |
STL |
| Slicing Software |
Integrated Slicer |
Integrated Slicer |
| Support Generation |
Automatic / Simple Support Generation |
Automatic / Simple Support Generation |
| Ethernet Port |
1 |
1 |
| USB Ports |
2 |
2 |
| Input Voltage |
230 V |
230 V |
| Cooling System |
Air Cooling |
Air Cooling |
| Machine Length |
617 mm |
24.29 in |
| Machine Width |
600 mm |
23.62 in |
| Machine Height |
1,770 mm |
69.69 in |
| Documentation |
Manual Included |
Manual Included |
| Identification Plate |
Available |
Available |
| Machine Configuration |
Compact Industrial Metal Additive Manufacturing System |
Compact Industrial Metal Additive Manufacturing System |
| Suitable Materials |
Stainless Steel, Tool Steel, Titanium, Cobalt-Chrome, Nickel Alloys, Precious Metal Powders |
Stainless Steel, Tool Steel, Titanium, Cobalt-Chrome, Nickel Alloys, Precious Metal Powders |
| Applications |
Rapid Prototyping, Dental Manufacturing, Medical Components, Research & Development, Education, Precision Engineering, Small Batch Production |
Rapid Prototyping, Dental Manufacturing, Medical Components, Research & Development, Education, Precision Engineering, Small Batch Production |
| Safety Features |
Closed Cartridge Powder System, Enclosed Build Chamber, Reduced Operator Exposure to Metal Powder |
Closed Cartridge Powder System, Enclosed Build Chamber, Reduced Operator Exposure to Metal Powder |
| Machine Features |
200 W Fiber Laser, Compact Footprint, 9 Build Cartridges Included, Integrated AL3D-OS Software, 15.6″ Touchscreen, Integrated Slicer, STL Import, 5 m/s Scan Speed, 50 μm Laser Spot, Air Cooling, Closed Powder Handling System, High-Density Metal Parts (>99%) |
200 W Fiber Laser, Compact Footprint, 9 Build Cartridges Included, Integrated AL3D-OS Software, 15.6″ Touchscreen, Integrated Slicer, STL Import, 5 m/s Scan Speed, 50 μm Laser Spot, Air Cooling, Closed Powder Handling System, High-Density Metal Parts (>99%) |
