HURCO DCX3226HT-5Si CNC Machine Specifications
Origin: Germany
Category: Milling CNC Vertical Machining Center Double Column 5 Axes
| Model | DCX3226HT-5Si |
|---|---|
| Table size | 118.1 x 82.7 in / 3,000 x 2,100 mm |
| Table T-slots | 9 x 0.87 in / 9 x 22 mm |
| Maximum weight on table | 30,864.7 lb / 14,000 kg |
| Spindle nose to table | 7.9 in (201 mm) / 51.2 in (1,301 mm) |
| X-axis | 126 in / 3,200 mm |
| Y-axis | 96.5 in / 2,450 mm |
| Z-axis | 43.3 in / 1,100 mm |
| B-axis | +/-110° |
| C-axis | +/-360° |
| Maximum spindle speed | 12,000 rpm |
| Spindle power (30 min / continuous) | 71 hp (53 kW) / 56.3 hp (42 kW) @ 2000 rpm |
| Spindle torque (30 min / continuous) | 186.6 ft. lbs (253 Nm) / 148.2 ft. lbs (200.5 Nm) @ 2000 rpm |
| Tool type | HSK 100 |
| Tool capacity | 40 |
| Maximum tool diameter | 4.9 in / 125 mm |
| Maximum tool length | 11.8 in / 300 mm |
| Maximum tool weight | 33 lb / 15 kg |
| Tool-to-tool ATC time | 3.5 sec |
| Rapid traverse XYZ per minute | XY = 591 in / 15 m Z = 394 in / 10 m |
| Programmable feedrate / minute | 394 in / 10 m |
| Maximum operating floor space (W x D x H) | 408.7 x 286.2 x 246.6 in / 10,382 x 7,270 x 6,263 mm |
| Machine weight | 96,562 lb / 43,800 kg |
