HARTFORD HSA-216 CNC Machine Specifications
Origin: Taiwan
| HSA-216 Specifications | |||
|---|---|---|---|
| Table | |||
| Working surface | 2000 × 3000 | mm | |
| T-slot (Width × Pitch × Number) | 22 × 180 (7) | mm | |
| Max. load (Average) | 8000 | kg | |
| Travel | |||
| X-axis travel | 1600 | mm | |
| Y-axis travel | 1500 (opt. for Z-axis box guideway) | mm | |
| Z-axis travel | 450 | mm | |
| Distance from spindle end to table (S) | Z780:160–940 | mm | |
| Distance from spindle end to table (M) | Z780:220–1100 | mm | |
| Distance between two columns | 430 | mm | |
| Spindle | |||
| Spindle nose taper | #40 / #50 | ||
| Spindle speed (DDS) | #40:15000 / #50:10000 | rpm | |
| Spindle speed (Gear) | #40:5000 / #50:2000 | rpm | |
| Spindle speed (Z-axis box guideway) | #50:6000 / 8000 | rpm | |
| Feed | |||
| Cutting feedrate (X/Y/Z) | 12 / 12 / 12 (opt. for Z-axis box guideway) | m/min | |
| Rapid traverse (X/Y/Z) | 24 / 24 / 20 | m/min | |
| ATC | |||
| Capacity | #40 A:32 / 40 ; #50 A:32 / 40 (opt.) 5:20 | pcs | |
| Max. tool weight | #40:7 / #50:18 | kg | |
| Tool shank | #40 BT-40 / CAT40 / DIN / BBT40 #50 BT-50 / CAT50 / DIN / BBTA50 / HSK-A63 | ||
| Pull stud bolt | P40T-1 / P50T-1 (CAT-40 / DIN 69872) | ||
| Max. tool size (diameter × length) | ø125 × 300L | mm | |
| Motor | |||
| Spindle drive motor (cont./30 min) | #40:11 / 7.5 (#50:15 / 18.5) opt. 15 / 18.5 | kW | |
| Positioning Accuracy | |||
| 3-axis linear scale (JIS B6330) without linear scale — Positioning Accuracy | ±0.010 | mm | |
| Repeatability | ±0.003 | mm | |
| 3-axis linear scale (JIS B6330) with linear scale — Positioning Accuracy | ±0.008 | mm | |
| Repeatability | ±0.003 | mm | |
| 3-axis rotary positioning accuracy (VDI3441) repeat 5 times | 0.015 | mm | |
| Repeatability | 0.007 | mm | |
| Other | |||
| Required air pressure | 4 / 5 | kg/cm² | |
| Electric power requirement | 45 / 50 | KVA | |
| Machine weight | 18000 / 21000 | kg | |
| Floor space | 8630 × 10630 × 5880 | mm | |
| Machine dimensions (L × W × H) | 6712 / 9040 × 4619 / 5433 × 8780 | mm | |
