DMTG Machine Tools DT-40H CNC Machine Specifications
Origin: China
Category: Lathe CNC
| DT-40H (SL-580H) CNC LATHE – TECHNICAL SPECIFICATIONS | |||
|---|---|---|---|
| Max. Swing Diameter over Bed | Ø580 mm | Max. Turning Diameter (Shaft/Disc) | Ø350 / Ø380 mm |
| Max. Turning Length | 555 / 1055 mm | ||
| Guideway Type | Linear Guideway | ||
| SPINDLE | |||
| Spindle Nose | A2-6 (Optional A2-8) | ||
| Chuck Size | 8 / 10 inch | ||
| Spindle Speed Range | 4000 / 3500 rpm | ||
| Spindle Bore | Ø70 / Ø87 mm | ||
| Max. Bar Capacity | Ø51 / Ø73 mm | ||
| Spindle Motor Power | 11 / 15 kW | ||
| TOOL POST | |||
| Turret | Live Tooling 12-position Turret | ||
| Tool Shank Size | 25 × 25 mm | ||
| Indexing Time | 0.49 / 0.96 s (ITALY) | ||
| TAILSTOCK | |||
| Quill Diameter | Ø85 mm | ||
| Quill Stroke | 140 mm | ||
| STANDARD ACCESSORIES | |||
| • Live tooling turret • Hydraulic chuck • Automatic lubrication • Coolant system | |||
| OPTIONAL ACCESSORIES | |||
| • Y-axis option • Chip conveyor • Tool presetter | |||
