Available now : used DATRON M8Cube CNC High Performance HSC Milling Machine Spindle 40k rpm – Year 2023 made in Germany
| DATRON M8Cube CNC High Performance HSC Milling Machine – Year 2023 | |
|---|---|
| Manufacturer | DATRON |
| Model | M8Cube |
| Year | 2023 |
| Condition | Excellent (Used) |
| Functionality | Fully Functional |
| Machine Type | CNC High Performance HSC Milling Machine |
| X-Axis Travel | 1,020 mm (40.2″) |
| Y-Axis Travel | 830 mm (32.7″) |
| Y-Axis Travel (with Tool Changer) | 720 mm (28.3″) |
| Z-Axis Travel | 245 mm (9.6″) |
| Portal Clearance | 200 mm (7.9″) |
| Maximum Feed Rate | 22 m/min (866 ipm) |
| Machine Dimensions (L × W × H) | 1,760 × 1,740 × 1,950 mm (69.3″ × 68.5″ × 76.8″) |
| Machine Weight | Approx. 1,300 kg (2,866 lb) |
| Machine Construction | Solid Concrete Polymer Table with Steel Frame, Gantry Design, Dual Y-Axis Drive |
| Drive System | Digital Servo Drives with Ball Screws on All Axes |
| Chip Removal | Integrated Central Chip Trolley |
| Enclosure | Fully Enclosed Cabin |
| CNC Control | DATRON next+ |
| High-Frequency Spindle | 3 kW, GMN HC80cg-40000, HSK-E25 |
| Maximum Spindle Speed | 40,000 RPM |
| Tool Holder | HSK-E25 |
| Automatic Tool Changer | 12 Positions |
| Handheld Control Unit | DATRON B10-2 CNC Handwheel |
| Camera System | DATRON next Camera Feature |
| Tool Length Measurement | DATRON Tool Length Probe with Blow-Off Station |
| Z-Probe | High-Precision TP-R Probe |
| Vacuum Distributor | 2-Circuit Pro Vacuum Distributor |
| Vacuum Pump | 250 m³/h, 3 × 400 V, 32 A |
| Vacuum Plate | Meander Slot Design, 1,000 × 700 × 30 mm (39.4″ × 27.6″ × 1.2″) |
| Applications | High-Speed Precision Milling of Aluminum, Plastics, Composite Materials, Graphite, Non-Ferrous Metals and Precision Components |
