TRIPET HAUSER HTT CNC TST 100 CNC-4R CNC Internal Grinding Machine – 4 Spindles (Year 1998)
Specifications
Grinding Length	300 mm
Max. Internal Grinding Diameter	0.5 – 75 mm
Centre Height (B-Axis)	130 mm
Z-Axis Travel / Resolution	340 mm / 0.0005 mm
U-Axis Cross Slide Travel	100 mm
B-Axis Travel	Manual, −30° / +60°
X-Axis Cross Slide Travel	50 mm
Grinding Spindle Speeds	Stepless, 4 spindles (rpm)
Tool Spindle Carrier Speed (B-Axis)	10 – 1500 rpm
Control System	Brüsch TPS 3000
Accessories
Centre chuck, 250 mm diameter
Coolant system
Machine Dimensions & Weight
Length	2500 mm
Width	2500 mm
Height	2300 mm
Machine Weight	3500 kg
