Açıklama
X Axis Travel mm 1600
Y Axis Travel mm 850
Z Axis Travel mm 750
mm 150-900
Table Table area mm 1800 x 850
Max. Load of table kg 2000
T- slot mm 5 x 18 x 150
Spindle Spindle taper – BT50 (ISO50)
Spindle Speed RPM 6000
Spindle Drive – Belt Gear head
Spindle Cooling – Oil cooler
Spindle Motor kw 15/18.5
Feed Rate Rapid Traverse X m/min 18
Rapid Traverse Y m/min 18
Rapid Traverse Z m/mm 15
Cutting feed rate mm/min 1-10000
X / Y/ Z Axes motor output kw 7.0 / 7.0 / 7.0
A.T.C. Magazine type (BT40) Arm Chain (opt.)
Tool Magazine capacity pcs 24 32
Max. tool diameter mm 110/220 125/220
Max. tool length mm 300 300
Max. tool weight kg 15 15
Tool Selection – Random Random
Others Power consumption KVA 40
Floor space (length) mm 4520
Floor space (width) mm 3510
Floor space (height) mm 3345
Machine weight kg 14000
box guideways
