Description
Soraluce TA 35 A – Year 2019
CNC Travelling Column Milling Machine
General data
Weight of the machine 18500kg
Control system
Brand HEIDENHAIN
Model iTNC 530 HSCI
Remote control Yes
Main drive
Number of spindles 1
Spindle speed range 20-4000
Spindle motor power 28 kW
Number of axes 3
Travel distance
X-axis travel 3500 mm
Y-axis movement 1500 mm
Z-axis movement 1200 mm
Table
Outer length 3700 mm
Outer width 1000 mm
Number of slots 6 x 22 H12
This SORALUCE TA-35A milling machine was manufactured in Spain in 2019.
It is equipped with a HEIDENHAIN iTNC 530 HSCI (3 axes + spindle) Rotary remote control unit with joint.
Includes a 19″ flat screen, metal keyboard with integrated mouse and
USB interface on the control panel.
Processor speed 0.5 ms also included.
Interpolation turning with HEIDENHAIN iTNC 530 consisting of CAM system,
HEIDENHAIN postprocessor, software adaptation C-axis.
The machine has a portable electronic handwheel HEIDENHAIN HR 410 with 3 m spiral cable.
Features an automatically switching milling head with 2.5° x 2.5° pitch and speeds up to 4000 rpm,
28 kW, 479 Nm, incl. air cooling/oil mist lubrication,
tool clamping force 20,000 N,
tool holder ISO 50 – DIN 69871 A (H200), not applicable if milling head H210 is selected.
Including a complete splash guard enclosure with a height of 2,600 mm.
Consisting of two front doors and one rear door for operating the machine from the front and rear.
All doors and walls are fitted with a total of 7 windows.
The hydraulic weight is compensated by a device acting directly on the vertical carriage.
Includes a machine table with 5 x T-slots 22 H12 (6 x T-slots for table width 1000 mm) and
a reference slot 22 H8,
T-slot spacing 140 mm.
