Description
X 800 x Y 800 x Z 800 mm
Table 500 x 630 mm
CN Siemens 840 D
HSK-80A cone
spindle 12.500 rpm
Max dimensions workpiece size: Ø 900 x 1000 (mm)
Maximum admissible load on table: 800 kg
Table indexing (B axis) 360,000 x 0.001 °
Spindle power 52 kW
Rapid 60 m / min 60-tool changer
Watering through the high pressure center
X 800 x Y 800 x Z 800 mm
Table 500 x 630 mm
CNC Siemens 840 D
Spindle speeds 12.500 RPM
Spindle taper HSK-80A
Max. dimensions of piece: Ø 900×1000 (mm)
Max. weight admitted on table: 800 kg
Indexing of B-axis 360,000 x 0.001 °
Spindle power 52 kW Rapids feeds 60 m / min ATC 60 tools
Coolant thru spindle
