Description
Chiron FZ18W CNC Vertical Machining Center – Year 1998
X Axis 750 mm
Y Axis 400 mm
Z Axis 600 mm
Table length 1240 mm
Table width 850 mm
Overhauled no
Technical specifications of CNC milling machine CHIRON FZ 18 W MAGNUM HIGH SPEED
– CNC controller : SIEMENS SINUMERIK 810M – Polish and German language
– work table surface (L x W) : 1240 x 850 mm
– feeds in X/Y/Z axis : 750/400/600 mm
– maximum spindle speed : 10500 rpm
– 20-position tool head
– machining accuracy (spacing) : 0.01 mm
– machining accuracy (circle milling) : 0.03 mm
– spindle taper : SK40
– computer for program transmission
– RS233 port
– total power consumption : 29 kVA
– power supply : 400 V
– dimensions (L x W x H) : 3143 x 1920 x 3000 mm
– machine weight : 5500 kg
The machine is in very good working condition, all the time in active production with service history and ongoing maintenance. The price does not include the vice. In addition, there is a table drill and 230V and 400V sockets outside the machine.
The offered CHIRON vertical milling center is equipped with, among other things, a computer for program transmission and an intuitive CNC SIEMENS SINUMERIK 810M control for programming machining cycles. The total weight of the machine is 5500 kg.
