Bavelloni Gemy 6 Glass Straight Edging Machine – Year 2009
Bavelloni Gemy 6 Glass Straight Edging machine.
Glass thickness: 3 – 35 mm
Min. glass size: 35 x 35 mm
Machining speed: 0,5 – 5 m/min
Year: 2009
In working order, can be viewed during production. Sold as is.
Price: EXW
Manufacturer Catalogue Information about
Bavelloni Gemy 6 Glass Straight Edging Machine :
Gemy 6 is the straight edging machine with 6-cup wheels, with innovative design and technology. It executes high quality work on thickness up to 35 mm and is equipped with a NC that, amongst various functions, also automatically adjusts the speed of the machine according to the thickness to be processed. Thanks to the use of ABS covers it proves exceptionally
soundproof and safe due to the complete acoustic and electrical insulation. .
Ergonomic and easy to use Multifunctional NC
Central lubrication
ABS covers
Possible regulation of the amount of glass to be removed (0÷5 mm with a 0,25 mm step) Front regulation of the wheel that executes the back arrise
Stainless steel casing and tanks
Technical data:
Workable glass thickness: 3 ÷ 35 mm
Min. workable dimensions: with corner chamfering (15 mm) 45 mm
Without corner chamfering 35 mm
Max weight allowed per meter of conveyance: 200 kg/m and total load 350 kg
Working speed 0,5 ÷ 5 m/min
Pneumatic feed: pressure 6 bar
Water tank: 1 x 360 liters
Total power installed: Kw 16.5
Total length (L) 6700 mm
Machine width (W) 1300 mm
Total height (H) 2300 mm
Height of working plane ≈ 840 mm
Total weight (with empty water tank): 2600 kg
Numerical control RS150
Operator interface CN 23
Programmable control (PLC) Integrated in the NC
Screen Liquid Crystal Display (LCD)
Operative keyboard Sensitive keys
