Metal length | 4070 mm |
---|---|
Power | 4000 W |
Metal width | 2050 mm |
Option to cut tubes | no |
Max thickness | 20 mm |
CNC | yes |
CNC type | Fanuc FS-160iLB |
Travel X | 4070 mm |
Travel Y | 2050 mm |
Travel Z | 200 mm |
Length x width x height | 12300.0 × 3350.0 × 2500.0 |
Weight | 14000 kg |
Worked hours | 31814 hours |
Working hours machine 31814 h
Laser power4000 Watt
Working range laser4070 x 2050 x 200 mm
Max. steel20 mm
Max. stainless steel16 mm
Max. aluminium10 mm
Length12300 mm
Width3350 mm
Height2500 mm
Machine weight14000 kg
Electrical connected load83 kVA
