TAKISAWA TT-2600ⅡWG CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Multi-Spindle 2 Spindles
| (Turning) | ||
|---|---|---|
| TT-2600ⅡWG | ||
| Chuck Size | inch | 12+12 |
| Type of Turret | 12-Station Turret (All-Holder Type) | |
| Max. Turning Diameter | mm | φ340 |
| Max. Turning Length | mm | 184 [OP. 166] |
| Spindle Speed | min⁻¹ | 2500 |
| Rotary Tool Speed | min⁻¹ | - |
| Rapid Traverse Rate | m/min | X : 24 / Z : 24 |
| Spindle Motor | kW | 15 / 11 (15 min / continuous) |
| Rotary Tool Motor (S3 25% / 15 min / continuous) | kW | - |
| Machine Height | mm | 4130 |
| Required Floor Space | mm | 3725 × 2938 |
| Machine Weight | kg | 6500 |
