TAKISAWA TMX-4000IIS CNC Machine Specifications
Origin: Japan
Category: Lathe CNC Multi-Tasking Turn Mill Machine
| TMX-4000IIS | ||
|---|---|---|
| Right Spindle Stock | ● | |
| Tailstock | - | |
| Lower Turret (12-Station) | - | |
| Chuck Size | inch | 10+10 |
| Type of Turret | Tool Spindle with ATC | |
| Max. Turning Diameter | mm | φ500 |
| Max. Turning Length *¹ | mm | 1500 |
| Bar Capacity (Left Spindle) *² | mm | φ80 |
| B-Axis Swivel Range | deg | 230 (±115) |
| Left Spindle Speed | min⁻¹ | 4000 |
| Right Spindle Speed | min⁻¹ | 4000 |
| Tool Spindle Speed | min⁻¹ | 12000 |
| ATC Tool Storage Capacity | 40 [OP. 80. 120] | |
| Rapid Traverse Rate | m/min | X1:40 / Z1:40 / Y1:40 / A:30 |
| Left Spindle Motor (S2 30 min / continuous) | kW | 26 / 22 |
| Right Spindle Motor (S2 15 min / continuous) | kW | 22 / 15 |
| Tool Spindle Motor (S3/S6 25%/cont.) | kW | High: 22 / 15 |
| Machine Height | mm | 3160 |
| Required Floor Space *³ | mm | T40: 6950 × 4478 |
| Machine Weight | kg | 17000 |
