PALMARY FCL-12 CNC Machine Specifications
Origin: Taiwan
Category: Grinding CNC Centerless
| Item | FCL-12 |
|---|---|
| Standard grinding range (dia.) | Ø1 ~ Ø40 mm |
| Capacity increases with special arrangement | Ø30 ~ Ø60 mm |
| Grinding wheel size (O.D. x width x I.D.) | Ø305 x 150 x Ø120 mm |
| Linear velocity | 33 m/s |
| Grinding wheel motor | 7.5 HP x 4P (5 kW) |
| Regulating wheel size (O.D. x width x I.D.) | Ø205 x 150 x Ø90 mm |
| Regulating wheel speed | 10 ~ 300 rpm (variable speed) |
| Regulating wheel motor | 1.5 kW servo motor |
| Regulating wheel tilt angle | +5° ~ -3° |
| Regulating wheel swivel angle | ±5° |
| Hydraulic pump motor | 1 HP x 4P |
| Coolant motor | 1/8 HP x 2P |
| Lubrication | Auto electric lubricator |
| Controller Brand | FANUC |
| Coolant tank capacity | 100 L |
| Hydraulic tank capacity | 53 L |
| Lubrication capacity | 4 L |
| Net weight | 1700 kg |
