MYLAS MING YANG MACHINERY 65B CNC Machine Specifications
Origin: Taiwan
Category: Lathe CNC Turning Milling Center 1 Turret 2 Spindle
| Model 65B | |
|---|---|
| Main Spindle | |
| Chuck dia | 8\" |
| Max. turning diameter | 180 mm |
| Max. turning bar diameter | 65 mm |
| Spindle nose | A2-6 |
| Hole through spindle | 79 mm |
| Spindle speed | 4000 rpm |
| Spindle motor | 7.5 / 11 kW |
| Sub Spindle | |
| Chuck dia | 6\" |
| Max. turning diameter | 180 mm |
| Max. turning bar diameter | 42 mm |
| Spindle nose | A2-5 |
| Hole through spindle | 55 mm |
| Spindle speed | 6000 rpm |
| Motor torque | 5.5 / 7.5 kW |
| Travel | |
| X1 travel | 186.5 mm |
| X2 travel | 175 mm |
| X3 travel | 145 mm |
| Z1 travel | 600 mm |
| Z2 travel | 600 mm |
| Z3 travel | 590 mm |
| Y1 travel | ±45 mm |
| Y2 travel | - |
| Tailstock travel | 100 mm |
| Quill taper | MT4 |
| Motor Rapid | |
| X1 axis | 24 m/min |
| X2 axis | 24 m/min |
| X3 axis | 24 m/min |
| Z1 axis | 36 m/min |
| Z2 axis | 36 m/min |
| Z3 axis | 36 m/min |
| Y1 axis | 18 m/min |
| Y2 axis | - |
| Turret | |
| Tool stations | 16 |
| Tool size | 20 mm |
| Boring bar holder | 25 mm |
| Live tool speed | 6000 rpm |
| Live tool torque | 17.7 / 23.6 Nm |
| Dimensions | |
| Coolant tank | 690 L |
| Machine width | 3600 mm |
| Machine depth | 1976 mm |
| Machine height | 2175 mm |
| Foundation | 4135 × 3195 mm |
| Power supply | 75 KVA |
