MECTRON MTS-C360W CNC Machine Specifications
Origin: Japan
Category: Milling CNC Vertical Machining Center
| Slide Travel X × Y × Z-Axis | 400 × 300 × 350 mm |
| Height of Spindle Nose from Table | 240 ~ 590 mm |
| Table Size (W × L) | 480 × 360 mm |
| Tables Max. Load Capacity | 70 kg (one side) |
| Table Exchange Method / Exchange Time | 2.3 sec (180° turn) |
| Max. Spindle Speed | 12,000 min⁻¹ |
| Rigid-Tap Speed | 5,000 min⁻¹ |
| Rapid Traverse Rate X, Y, Z-Axis | 48, 48, 48 m/min |
| Shank of Tool Holders | BBT30 + P30T-II |
| Tool Change System | Double arm system |
| No. of Tool Pot | 25 pcs |
| Max. Tool Diameter × Tool Length | φ80 × 200 mm (Adjacent tools φ65 × 200) |
| Max. Tool Weight (total) | 2.5 kgs |
| Tool Change Time Tool-to-Tool / Chip-to-Chip | 0.7 / 2.4 sec |
| Max. Height of Machine | 2,285 mm |
| Min. Height of Machine | 2,185 mm |
| Size of Machine (Width × Depth) | 1,700 × 2,700 mm |
| Machine Weight | 3,700 kgs |
| NC Unit | FANUC 0i-MF Plus |
| Power Supply Voltage | AC200 ~ 230V 3 Phase |
| Power Capacity Required | 17.0 KVA |
| Positioning Accuracy / Repeated Positioning Accuracy | 0.005 / ±0.003 mm |
| Machining Capacity Drilling/Tapping (ADC12) | φ34 F0.2 / M27 × 3.0 mm |
| Machining Capacity Drilling/Tapping (FC250) | φ30 F0.2 / M24 × 3.0 mm |
| Machining Capacity Drilling/Tapping (S45C) | φ26 F0.15 / M20 × 2.5 mm |
