Mazak POWER MASTER CHUCKER – Year 2000
CNC Lathe
Condition:used
Year:2000
Cnc control:Mazatrol PC-Fusion 640T
Swing over bed:42”
Turning diameter:39”
Swing over gap:48”
Width of gap:20”
X-axis travel:25”
Z-axis travel:45”
Spindle bore:12 1/2”
Front:SMW 630-325 ES
Rear:SMW 630-325 ES
Spindle speed:0-750 rpm
Turret stations:8 stations
Chip conveyor:Yes
Main motor:60 hp. 3/60/220v.
Machine weight:22,800 lbs.
Spindle Bore:12 1/2”
MAZAK PMC CNC LATHE
Chucks
It has been disassembled and cleaned.
Both chucks have been removed, cleaned, new O-ring kits installed and
checked in the open and closed position overnight. The front chuck is in good condition, 80% of new. The rear chuck is in poor condition, 20% of new. For pipe all the rear chuck does is center and hold so this should not be any particular problem for the near future.
Mazak Oil Country Powermaster Pipe threader
