EIMELDINGEN RUSACH Rotary Table for Heavy Machining And Metrology Applications with High Accuracies & Heavy Load Capabilities
Quantity: 2 Units
Table Model: 5-1010
Table Serial Numbers: V10 142 / V10 143
Slide Model: FT7-MF158-SF50-T59
Slide Serial Number: 274
Equipped With
- 39.5″ Eimeldingene Model 5-1010 Power Rotary Table with Fanuc Servo Motor Drive
- Active Clamping Mechanism
- 39.5″ Eimeldingene Tailstock
- Eimeldingene PT7-MF158-S50-T59 Heavy-Duty Master Slide
- Hydraulic / Pneumatic Clamping Unit
- Heidenhain Measuring System
- Ball Screw
- Emerson Inverter Duty Drive
Overall Specifications
| Specification | Metric | Imperial |
|---|---|---|
| Table Diameter | 1000 mm | 39.37″ |
| Number of T-Slots | 8 | |
| Center Hole | 100 mm | 3.94″ |
| Distance Between Centers (Approx.) | 2743 mm | 108″ |
Rotary Table Specifications
| Specification | Metric | Imperial |
|---|---|---|
| T-Slot Dimensions | 18 mm | 0.71″ |
| Load Capacity (Uniform) | 6000 kg | 13,200 lbs |
| Overall Length | 610 mm | 24.02″ |
| Overall Width | 1010 mm | 39.76″ |
| Overall Height | 1300 mm | 52.16″ |
| Permitted Machining Force | 80,000 N | 17,600 lbs |
| Clamping Torque | 22,000 Nm | 190,550 lbs |
| Maximum Milling Torque | 19,000 Nm | 164,567 lb/in |
| Main Gear Ratio | 360 : 1 | |
Note: These rotary tables are suitable for heavy machining and metrology applications requiring high accuracy and high load capacity.
